IP54 Toolless Mounting LED recessed linear light fixture DALI Dimmable

Product Categories
Shenzhen Recolux Lighting Company Limited
Contact Now

IP54 Toolless Mounting LED recessed linear light fixture DALI Dimmable

  • 1
  • 2

Model Number : RIP5S-60-S1

Certification : ENEC, CE, RoHS, CB

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T, L/C, Paypal

Supply Ability : 15,000 Pieces per Month

Delivery Time : 3-5 working days for sample, 7-15 working days for mass production

Packaging Details : 8pcs per carton(159*29*22cm)

Input Voltage : 220-240V AC/DC

LED : SMD2835

Input Frequency : 50 or 60 HZ

Lifetime : 50,000(L80B10)

Power Factor : >0.95

Beam Angle : 30°/60°/90°/25°/15°/120°

Switching Cycles : 100,000 times

CRI : Ra>80 or Ra>90

IP Degree : IP54

Protection Class : Safety class I

UGR : <23

Driver : Tridonic, Osram, , VS

SDCM : <5

Luminous Efficacy : 160lm/w

Flicker Free : Yes

Emergency : 4W 3H

Sensor : Microwave

Dimmable : DALI, 0-10V

Material : Aluminum+PMMA

Warranty : 5 Years

Contact Now

Up to 180 lm/w ip54 toolless mounting dustproof dali dimmable recessed led linear lighting

Our products are made of quality parts and have a high energy saving level. We think quality is very important so we always make sure our products are tested and have the right certifificates like TÜV. We are convinced that this is an added value for the installer.
  • 60W 55W 50W 40W with selector switch. With the switch, the luminaire output can be adjusted at any time.

IP54 Toolless Mounting LED recessed linear light fixture DALI Dimmable

​Datasheet for LED module:

Item Model NO. Watt Lumen Efficacy Function EEC L*W*H(mm)
1 RIP5S-60-S1 60W-50W-42W-32W 9,000lm 160LM/W On/off A++ 1451*65*27
2 RIP5S-60-V1 60W-50W-42W-32W 9,000lm 160LM/W On/off A++ 1451*65*27
3 RIP5S-68-PC 68W-60W-54W-48W-38W
32W-25W-20W by switch		 10,500lm 160LM/W On/off A++ 1451*65*27
4 RIP5S-72-B3 72W-68W-64W-60W-56W-54W-52W-50W-48W-45W 10,500lm 160LM/W 0-10V A++ 1451*65*27
5 RIP5S-68-T4 Max 68W 10,500lm 160LM/W DALI A++ 1451*65*27


Maximum Loading:

RIP5S-60-S1 RIP5S-60-V1 RIP5S-68-PC RIP5S-72-B3 RIP5S-68-T4
B10 12 13 15 15 13
B16 19 21 24 25 21
C10 20 22 25 27 21
C16 32 35 40 42 35

​Datasheet for trunkings:

Item Model NO, Wires(mm²) Dimensions(mm) Weight(KG)
1
TKB5-05W-00
5 x2.5 mm²
1450x 65 x 65
 1.59
2 TKB5-07W-00
7 x2.5 mm²
1450x 65 x 65
 1.65
3 TKB5-11W-00
11 x2.5 mm²
1450x 65 x 65
 1.95
4 TKB9-05W-00
5 x2.5 mm²
2900x 65 x 65
 2.85
5 TKB9-07W-00
7 x2.5 mm²
 2900x 65 x 65 2.98
6 TKB9-11W-00
11 x2.5 mm²
 2900x 65 x 65 3.25

Accessories:

IP54 Toolless Mounting LED recessed linear light fixture DALI Dimmable

FAQ:

Q1. Do you have other led lights?
A: Yes, we also have IP20 LED Linear Trunking System, LED Batten, LED Track Panel, etc.


Q2. What are functional products?
A: Such as 0-10v dimming, DALI dimming, emergency, motion sensor etc.


For more information, welcome to visit our website www.recolux.com.

RIP5S-60-S1
